1:10 Gradient Rubber Disability Access Ramp – 900mm Wide

1:10 Gradient Rubber Ramp – 900mm Wide (Recycled Tyre Rubber)

Australian-made • Durable • Safe • NDIS-friendly

Improve access instantly with the Tyrex 1:10 Gradient Rubber Ramp – a strong, stable and environmentally friendly solution designed to make thresholds safer for wheelchair users, mobility aids, walkers, scooters, prams and trolleys.

Made in Australia using recycled tyre rubber, this 900mm-wide threshold ramp provides a smooth transition over small steps, doorways, sliding door tracks and uneven surfaces. The 1:10 gradient offers a gentle, easy-to-navigate incline suitable for homes, workplaces, aged-care facilities and commercial environments.

Key Features

• 1:10 gradient for a gentle, safe incline over common thresholds
• Australian-made from recycled car tyre rubber
• Slip-resistant, UV-resistant surface for indoor and outdoor use
• Heavy-duty construction designed for long-term durability
• Simple installation – place against the step or fix in position if required
• Optional side wings to extend the ramp and reduce edge drop-off
• NDIS-friendly option for improved accessibility at home or work

Dimensions – 900mm Standard Width

This product is a 1:10 gradient ramp with a fixed width of 900mm (C). Height and length will vary based on your selection.

• Width (C): 900mm
• Gradient: 1:10
• Height (A): choose your required height
• Length (B): calculated as Height (A) × 10

Example: a 10mm height results in a 100mm ramp length.

The table below shows the matching ramp length (B) for each height (A). Width (C) is fixed at 900mm.

Please note prices shown are for the ramp only. Shipping is calculated separately based on total order weight and location. Please use the “Request a quote” button and we’ll be happy to help with accurate delivery pricing.

This product can be purchased GST-free by eligible NDIS participants.

To receive a quote or invoice for a GST-free NDIS order, please let us know you are an NDIS participant and provide:

• NDIS participant number
• NDIS plan start and end dates

Height (A)	Length (B)	Width (C)	Price (AUD)
10mm	100mm	900mm	$54.00
15mm	150mm	900mm	$58.00
20mm	200mm	900mm	$66.00
25mm	250mm	900mm	$84.00
30mm	300mm	900mm	$99.00
35mm	350mm	900mm	$116.00
40mm	400mm	900mm	$135.00
45mm	450mm	900mm	$150.00
50mm	500mm	900mm	$174.00
55mm	550mm	900mm	$199.00
60mm	600mm	900mm	$214.00
65mm	650mm	900mm	$243.00
70mm	700mm	900mm	$282.00
75mm	750mm	900mm	$309.00
80mm	800mm	900mm	$337.00
85mm	850mm	900mm	$345.00
90mm	900mm	900mm	$385.00
95mm	950mm	900mm	$405.00
100mm	1000mm	900mm	$445.00
105mm	1050mm	900mm	$465.00
110mm	1100mm	900mm	$499.00
115mm	1150mm	900mm	$529.00
120mm	1200mm	900mm	$559.00
125mm	1250mm	900mm	$589.00
130mm	1300mm	900mm	$634.00
135mm	1350mm	900mm	$669.00
140mm	1400mm	900mm	$733.00
145mm	1450mm	900mm	$770.00
150mm	1500mm	900mm	$805.00
155mm	1550mm	900mm	$900.00
160mm	1600mm	900mm	$930.00



Standard heights are available up to 160mm. Larger or unusual sizes can be made as custom ramps.

Ideal Locations

These threshold ramps are suitable for:

• Homes and apartments
• Aged care and disability support facilities
• Retail, hospitality and office spaces
• Industrial and warehouse environments
• Sliding door tracks, entry thresholds, internal transitions, garages and patios

Optional Add-ons

Side Transition Wings (1:10 Gradient)

• Extend ramp coverage and create a smoother side entry
• Must be ordered at the same height and gradient as your ramp

Need side wings for angled entry? Click here to view the matching 1:10 Ramp Wings.

Alternative to wings: If side wings are not a suitable option due to space or other constraints, optional safety kerbing provides a defined edge barrier to improve safety and confidence.

View and add safety kerbing to your quote here.

Custom Ramps

• Non-standard widths, heights or gradients available on request
• Contact us with your measurements for a tailored quote

Lead Times

• Up to 100mm high: typically 1–5 working days
• 105mm to 160mm high: typically 5–10 working days
• Custom items: varies depending on complexity, but usually up to 15–20 working days

NDIS Information

This product is suitable for NDIS participants and is typically funded under consumables (low cost assistive technology).

• Self-managed: request a quote or invoice, then claim through your NDIS portal once paid.
• Plan-managed: request an invoice so your plan manager can process payment.

Measuring & Installation

To select the correct size, measure the vertical height of the step or threshold. Ramp length is calculated using the simple formula:

Ramp length (B) = Height (A) × 10

Most ramps can be placed directly against the step on a clean, stable surface. For heavier ramps or complex layouts, professional installation is recommended.

Ramp gradient guidance (AS 1428.1)

Australian Standard AS 1428.1 provides guidance on ramp gradients used to overcome small steps and thresholds.

• Up to 35 mm height – maximum gradient 1:8
• 35 mm to 190 mm height – maximum gradient 1:10

These guidelines are commonly used when designing accessible environments, particularly in public and commercial buildings. For private residential settings they are generally used as best-practice guidance. In situations such as where space is limited, steeper ramps can still be installed.

Why Choose a Tyrex Rubber Ramp?

Tyrex has been manufacturing high-quality recycled rubber access products in Australia since 1990. Their ramps are known for:

• Exceptional durability and stability
• Eco-friendly use of recycled materials
• Proven performance in both domestic and commercial settings
